SureCall Flare 3.0 - Kitting Information

SureCall Flare 3.0 | Specifications
English
18
1-888-365-6283 | support@surecall.com | www.surecall.com
Kitting Information
Component
Product
number Gain/Loss Note
LTE-A
707 MHz
LTE-V
731 MHz
Cellular
800 MHz
PCS
1900 MHz
AWS
1700 / 2100 MHz
Outdoor Antenna*
SC-289W 3 dBi 3 dBi 3 dBi 4 dBi 4 dBi / 4 dBi
SC-231W 8 dBi 8 dBi 8 dBi 10 dBi 10 dBi / 10 dBi
Outdoor Cable*
SC-RG6-50 3.32 dB 3.32 dB 3.95 dB 6.42 dB 6.22 dB / 6.68 dB 50 Feet or longer
SC-RG11-50 2.29 dB 2.29 dB 2.53 dB 3.73 dB 3.68 dB / 4.51 dB 50 feet or longer
Indoor Antenna
SC-322W 2.5 dBi 2.5 dBi 3 dBi 5 dBi 4 dBi / 5 dBi
*Note: The Flare 3.0 booster is suitable for use with all equivalent and lower gain antennas, as well as, equivalent or greater lengths of cable.
PreAGC PreAGC
Pulse GSM 4.1 MHz AWGN
Frequency (MHz) Input (dBm) Output (dBm) Gain (dB) Input (dBm) Output (dBm) Gain (dB)
Uplink: 1710-1755 -49.5 20.0 69.5 -49.0 19.4 68.4
Uplink: 1850-1915 -49.5 22.1 71.6 -45.8 21.6 67.4
Uplink: 824-849 -39.3 25.3 64.5 -36.6 26.0 62.6
Uplink: 698-716 -36.8 25.0 61.8 -37.1 25.2 62.3
Uplink: 777-787 -38.6 22.1 60.7 -38.4 20.5 58.9
Downlink: 2110-2155 -55.2 12.5 67.7 -57.0 10.4 67.4
Downlink: 1930-1995 -57.2 11.2 68.4 -60.4 8.2 68.6
Downlink: 869-894 -51.2 11.8 63.0 -50.8 10.9 61.7
Downlink: 728-746 -47.5 14.5 62.0 -50.7 10.7 61.4
Downlink: 746-757 -45.8 11.8 57.6 -49.4 8.5 57.9
