INSTALLATION
SureCall Force-5 Cellphone-Mate, Inc. Page 11
All rights reserved.
Switch settings are cumulative. This means the total amount of attenuation for a
channel equals the combined dB of all DIP switches in the same bank being set to
ON.
Tip: The Force-5 signal booster comes unattenuated or fully powered. If you cannot
obtain sufficient antenna separation, use the DIP switches to attenuate the booster’s
dB gain.
To
Achieve...
Set the DIP Switches in the Same Bank as Follows...
SW1
(1 dB)
SW2
(2 dB)
SW3
(4 dB)
SW4
(8 dB)
SW5
(16 dB)
0 DB
OFF
OFF
OFF
OFF
OFF
1 DB
ON
OFF
OFF
OFF
OFF
3 dB
ON
ON
OFF
OFF
OFF
7 dB
ON
ON
ON
OFF
OFF
15 dB
ON
ON
ON
ON
OFF
21 dB
ON
OFF
ON
OFF
ON
31 dB
ON
ON
ON
ON
ON
