SureCall Force-5 Cellphone-Mate, Inc. Page 7
All rights reserved.
Installation Instructions
The Force-5 signal booster is suited for installation in a building or home.
Step 1. Connect the Outside Antenna
1. Mount the fiberglass antenna in an outside mounting location that:
x Has at least a 12-inch radius clear of obstructions and other radiating
elements.
x Is at least 75 feet in a straight line from the inside antenna when used in
an area prone to weak cellular signals and operating the booster at full 65
dB gain.
x Is not co-located or operating with any other antenna or booster.
FCC 27.50(d)(4) Statement: Fixed, mobile, and portable (hand-held) stations
operating in the 1710 – 1755 MHz band are limited 1 Watt EIRP. Fixed stations
operating in this band are limited to a maximum antenna height of 10 meters above
ground. Mobile and portable stations operating in this band must employ a means for
limiting power to the minimum necessary for successful communications.
2. Using the CM400 cable, connect the outside antenna to the booster connector
marked OUTSIDE (see page 5).
3. Hand tighten the connection.
Step 2. Connect the Inside Antenna
1. Mount the inside antenna:
x Omnidirectional dome antenna: mount the antenna on the ceiling in a
central location where you want reception.
x Panel antenna: install the antenna
