SurePrint SP91 - Page 57

SP91 User Manual
[Reference] GS
GS
GS
GS H
H
H
H , GS
GS
GS
GS k
k
k
k
GS
GS
GS
GS h
h
h
h n
n
n
n
[Name] Set bar code height
[Format] ASCII GS h n
Hex 1D 68 n
Decimal 29 104 n
[Range] 1 ≤ n ≤ 255
[Description] Set bar code height
n set vertical dot
[Default] n = 162
[Reference] GS
GS
GS
GS k
k
k
k
① GS
GS
GS
GS k
k
k
k m
m
m
m d1
d1
d1
d1 .
.
.
. dk
dk
dk
dk NUL
NUL
NUL
NUL ② GS
GS
GS
GS k
k
k
k m
m
m
m n
n
n
n d1
d1
d1
d1 .
.
.
. dn
dn
dn
dn
[Name] Set bar code
[Format] ① ASCII GS k m d1 ... dk NUL
Hex 1D 6B m d1 ... dk 00
Decimal 29 107 m d1 ... dk 0
② ASCII GS k m n d1 ... dn
Hex 1D 6B m n d1 ... dn
Decimal 29 107 m n d1 ... dn
[Range] ① 0 ≤ m ≤ 6 (k and d decided by the used bar code system )
② 65 ≤ m ≤ 73 (n and d decided by the used bar code system )
[Description] Select bar code system and print bar code.
m select the following bar code system
m
Bar code
system
Character number Notes
①
0 UPC-A 11
≤
k
≤
12 48
≤
d
≤
57
1 UPC-E 11 ≤ k ≤ 12 48 ≤ d ≤ 57
2 JAN13 (EAN13) 12 ≤ k ≤ 13 48 ≤ d ≤ 57
3 JAN8 (EAN8) 7
≤
k
≤
8 48
≤
d
≤
57
4 CODE39 1 ≤ k
48 ≤ d ≤ 57, 65 ≤ d ≤ 90, 32, 36, 37,
43, 45, 46, 47
5 ITF 1 ≤ k (k is even) 48 ≤ d ≤ 57
6 CODABAR 1 ≤ k
48 ≤ d ≤ 57, 65 ≤ d ≤ 68, 36, 43,
45, 46, 47, 58
7
Standard
EAN13
12 ≤ k ≤ 13 48 ≤ d ≤ 57
8 Standard EAN8 7 ≤ k ≤ 8 48 ≤ d ≤ 57
②
65 UPC-A 11 ≤ n ≤ 12 48 ≤ d ≤ 57
66 UPC-E 11 ≤ n ≤ 12 48 ≤ d ≤ 57
67 JAN13 (EAN13) 12 ≤ n ≤ 13 48 ≤ d ≤ 57
68 JAN8 (EAN8) 7 ≤ n ≤ 8 48 ≤ d ≤ 57
69 CODE39 1 ≤ n ≤ 255
48
≤
d
≤
57, 65
≤
d
≤
90, 32, 36,
37, 43, 45, 46, 47
