6-28
FUEL HOSE
Lift the fuel tank by referring to the
FUEL TANK section.
Inspect the fuel hose for damage
and fuel leakage. If any defects
are found, the fuel hose must be
replaced. Replace the fuel hose
every four years.
CLUTCH ADJUSTMENT
Adjust the clutch cable play as fol-
lows:
Minor Adjustment
(Quick Adjuster)
Turn adjuster 1 so the clutch
lever clearance A measured at
the lever holder obtains 2 – 3 mm
(0.08 – 0.12 in) when squeezing
the lever until pressure is felt.
To Next Page
