6-12
FUEL TANK
Fuel tank Removal
1. Remove the bolts 1 and the
seat 2.
2. Remove the bolts 3 and the
right and left radiator covers
4.
3. Disconnect the fuel pump cou-
pler 5.
4. Remove the fuel tank bolt 6
and rubber band 7.
5. Lift and hold the fuel tank.
Clean the retainer A and fuel
hose connector B.
To Next Page
