Section II: Installation - Accessories
MATERIAL LIST FOR 11H14
ITEM PART # QTY DESCRIPTION WT-lb/ea.
1 10H74 6 Fender Bracket Wdmt 8.05
2 21H37 6 Mounting Plate 1.09
3 21H42 6 Rubber Spacer 0.85
4 21H61 6 Fender Tube 1.26
5 00P34 48 3/8-16 UNC Locking Nut 0.02
6 00P44 24 3/8-16 UNC x 1 1/2 HHCS 0.07
7 00P78 24 Ø3/8” Nylon Washer 0.01
8 00P99 8 3/8-16 UNC x 4 HHCS 0.11
9 01P21 16 3/8-16 UNC x 2 1/2 HHCS 0.09
10 90P36 2 Fender, Steel Tandem 77.00
11 00771 72 Ø3/8” Flat Washer 0.05
NOTE:
1. PRIOR TO ANY WELDING, CONSULT THE TRUCK MANUFACTURE FOR ANY SPECIAL PRECAUTIONS
THAT MAY NEED TO BE TAKEN. TYPICALLY THE BATTERIES MUST BE DISCONNECTED AND THE
GROUND LEAD FROM THE WELDER SHOULD BE AS CLOSE TO THE PART BEING WELDED TO AVOID
THE POSSIBILITY OF ARCING ACROSS BEARINGS, GEARS, ETC.
