Section II: Installation - Accessories
2.8.INS.ACC.LEDLB
NOTE:
1. PRIOR TO ANY WELDING, CONSULT THE TRUCK MANUFACTURE FOR ANY SPECIAL PRECAUTIONS
THAT MAY NEED TO BE TAKEN. TYPICALLY THE BATTERIES MUST BE DISCONNECTED AND THE
GROUND LEAD FROM THE WELDER SHOULD BE AS CLOSE TO THE PART BEING WELDED TO AVOID
THE POSSIBILITY OF ARCING ACROSS BEARINGS, GEARS, ETC.
Figure 3
MATERIAL LIST FOR 51H68
ITEM
PART #
QTY
DESCRIPTION
WT
-
lb/ea.
1
51H69
2
Stub Light Bar Weldment
8.54
2
63H08
1
Center Plate
27.33
3
00P44
6
3/8
-
16 x 1 1/2 HHCS
0.07
4
00P34
6
3/8
-
16 Locking Hex Nut
0.02
5
00771
6
Ø3/8 Flat Washer
0.01
6
01P18
4
5/8
-
11 x 3 HHCS
0.35
7
00P81
8
#8
-
32 x 1 RHMS
-
8
00P82
8
#8
-
32 Hex Nut
-
9
00P83
8
#8 Lock Washer
-
10
40P32
1
Lic. Light Assy (w/o Harness)
-
11
40P34
REF
License Lamp Harness
-
12
40P35
REF
Id Light Bar Rail
-
13
40P37
REF
Id Light Bar Harness
-
14
40P38
REF
Junction Box Assembly
-
15
40P39
REF
Light Kit Assembly
23.00
16
40P40
REF
Right Tail Light Module w
/ Harness
-
17
40P41
REF
Left Tail Light Module w
/ Harness
-
18
40P42
REF
Side Marker Lamp
-
19
40P43
REF
Stop, Turn, & Tail Lamp
-
20
40P44
REF
License Lamp
-
21
40P45
REF
Back
-
Up Lamp
-
22
40P46
REF
ID
Light Bar Lamp
-
Figure C
2-26
