SectionIV:Maintenance
4.0.MAI.SL-520X
ADJUSTMENT
Should the jib lockout valve need adjustment follow the steps below (refer to the illustration on
the previous page).
1. Loosen the mount bracket screws enough that the mount bracket can slide.
2. Place a 1/16” spacer between the roller and the ramp.
3. Tighten the adjustment bolt until the roller is completely or near completely compressed.
4. Tighten the mount bracket screws.
5. Remove the spacer.
6. Test function.
PART NUMBER &
SPECIFICATION
SwapLoader
Pt. No.
Work Port Size Spool Type
23P04 7/8-14 ORB (SAE 8) 2-Way, 2-Position N.C.
Please contact your SwapLoader Distributor or SwapLoader USA should you have any
questions regarding this procedure.
