Technical Description
Technical Data
CONDUCTOR RE Controller
Technical data applicable to the CONDUCTOR RE controller (W1/W3) is
specified below.
Item Data
Designation CONDUCTOR RE (W1/W3)
Storage temperature -40 °C to +80 °C
Operating temperature -20 °C to +50 °C
Degree of protection IP 32
Dimensions 121 x 193 x 44 mm
Supply voltage 24V AC ± 10%
Power consumption 1 VA
Control function PI
P-band, cooling/heating
increments
1 K
Dead band, occupancy in
room
Depends on switching in cooling and switching in
heating
Dead band, no occupancy Depends on switching in cooling and switching in
heating
Frost protection 10 °C
Valve installation 1 time/48h period (fully open for 3 minutes)
Installation Mounting holes in enclosure or onto DIN rail
Connections Wiring terminal for 2.5 mm² multicore cable
Data communication ModBus RTU
Wireless communication 433 MHz band radio modem with room unit
(thermostat)
Inputs
Condensation sensor Resistance
Temperature sensor Resistance
Presence detector No occupancy/NO/NC (optional), default = NC for
occupancy
Window contact
(W3) No occupancy/NO/NC (optional), default = NC for
closed window
Carbon dioxide sensor 2 - 10 V, or 24 V
Pressure sensor / ModBus RTU
sensor
2 - 10 V / RJ12 cable
Modular contact RJ12 6-pole for connecting up to the room unit
(thermostat)
RJ12 6-pole for connecting up to ModBus RTU
Outputs
Actuator, heating 24 V AC, PWM (on/off or 0 - 10 V) max load: 72
VA = 12 actuators
Actuator, cooling 24 V AC, PWM (on/off or 0 - 10 V) max load: 72
VA = 12 actuators
Supply air damper
(W3) 0 - 10 V DC (low/normal/high) max load 25 VA =
5 actuators.
Extract air damper
(W3) 0 - 10 V DC (low/normal/high) max load 25 VA =
5 actuators.
