Installation
To be installed above a false ceiling
If a DIN rail is NOT available pre-mounted or is not available, the controller
can be appropriately mounted above the false ceiling (not on the module).
2
1
Figur 2. To mount the controller.
Pos 1. Supporting surface, NOT for the comfort module or climate beam.
Pos 2. Screws.
1. Secure the controller by means of screws in the upper left-hand and
the lower right-hand corners. Use screws suitable for the supporting
surface.
