Service
Display image Description
P_106 2
Application type
min 1 max 14
Indicates which application the
controller is set to run.
1 = W3
2 = W1
P_107 1
Relay at emer. 0=Op. 1=Cl. 2=No act.
min 0 max 2
Indicates the status of the relay
for the EMERG mode.
0 = Open
1 = Closed
2 = No action
P_108 48 hour
Valve exercise (h) 0=Not used
min 0 max 96
Indicates how often the valves
should be exercised (how many
hours shall pass between two
exercise runs).
P_109 20 min
Motion timer delay (min)
min 0 max 60
Indicates the number of
minutes after which the
controller should switch from
AUTO to ECON after the last
occupant has left the room.
P_110 60 min
Warning delay from start-up (min)
min 0 max 720
Indicates the number of
minutes after which the
controller shall be permitted
to initiate an alarm following a
start up.
P_111 120 min
Warning delay, PI-overload (min)
min 0 max 720
Indicates the number of
minutes after which the system
should initiate an alarm for
a +100% or -100% output
signal.
P_112 120 min
Warning delay, Set point (min)
min 0 max 720
Indicates the number of
minutes after which the system
should initiate an alarm, if the
temperature, flow or pressure
setpoint has not been reached.
P_113 30 min
Warning delay, pressure sensor (min)
min 0 max 720
Indicates the number of
minutes after which the system
should initiate an alarm if no
signal is received from the
pressure sensor or flow sensor.
P_114 0
Room Number (optional)
min 0 max 32000
Indicates the room number.
P_118 0 h
Zero calibration (h) 0=not used
min 0 max 720
Zero point calibration of the
Modbus-pressure sensor.
Indicates hours between
calibration.
P_119 3 min
Zero calibration wait (min)
min 1 max 6
Indicates the delay before the
calibration starts. (The damper
blade should have time to
close)
P_120 set 2 ID
MBS Modbus Address
min 1 max 247
Modbus address for the pipe
work contractor in BMS mode
(Modbus 1)
