Service
ModBus-register W1 applies to software after 0.76
Input register 16 bit integer register Read only
Modbus Name Min/Max Remarks Default
3x0001 Component Name ID 0/10 ID for type of controller in Conductor and
Wise system
00003
3x0002 - 0017 Component Name 0/999 Name built of max 16 chr, exch chr (ASCII
standard)
0
3x0018 Application ID
3x0019 HW Serial No.
3x0020 SW version
3x0021 Not used
3x0022 Application state 0/8 0=Init, 1=Auto Normal, 2=Auto Economy,
3=Manual, 4=Stand-by, 5=Emengency,
6=NightCool
3x0023 Not used
3x0024 Not used
3x0025 Time since last boot (Year)
3x0026 Time since last boot (Hours) 0/8760 After 8760h Year is updated
3x0027 Time since last boot (Minutes) 0/60 After 60min Hour is updated
3x0028 Temp sensor regulator Cels. Scaling 1:10
3x0029 Temp sensor RU1 Cels. Scaling 1:10
3x0030 Temp sensor RU2 Cels. Scaling 1:10
3x0031 Temp set point RU Setpoint in regulator form parameter or
Room Unit
3x0032 Not used
3x0033 Battery level RU Volts. Scaling 1:10
3x0034 Not used
3x0035 Not used
3x0036 Not used
3x0037 Input Analog 1 0/10000 (mV)
3x0038 Input Analog 2 0/10000 (mV)
3x0039 Input Analog 3 0/10000 (mV)
3x0040 Input Analog 4 0/10000 (mV)
3x0041 Output PWM 1 0/100 (%)
3x0042 Output PWM 2 0 /100 (%)
3x0043 Output PWM 3 0 /100 (%)
3x0044 Output PWM 4 0 /100 (%)
3x0045 Output Analog 1 0/10000 (mV)
3x0046 Output Analog 2 0/10000 (mV)
3x0047 Output Analog 3 0/10000 (mV)
3x0048 Output Analog 4 0/10000 (mV)
3x0049 PID Water Out -100/100 (%)
3x0050 PID ChangeOver Out -100 /100 (%)
3x0051 Not used
3x0052 Not used
3x0053 Cool Water 0/100 (%)
3x0054 Warm Water 0/100 (%)
3x0055 Not used
3x0056 Not used
