Swegon SILVER C RX - 6.2 SILVER C PX Dimensions

GB.SILVERSK.170901
We reserve the right to alter specifications.
34 www.swegon.com
D
EE
52
52
16 52*
50
J
K
50 50
J
K
80
50
SILVER SILVER
SILVER
6.2 Dimensions, SILVER C PX one-piece air handling units with plate
heat exchanger
SILVER C 04/05, 07/08
SILVER C 11/12
52
52
32 32
180
50 50
16 52*
SILVER SILVER
* The air handling unit is supplied without end connection panel if a duct accessory housed in an insulated casing will be connected.
* The air handling unit is supplied without end connection panel if a duct accessory housed in an insulated casing will be connected.
80
D
EE
M M
52
50
50
52
N
SILVER
SILVER
*
* The air handling unit is supplied without end connection panel if a duct accessory housed in an insulated casing will be connected.
SILVER C 14/20, 25/30
Size A B C D E F G H I J K L M N Ø Weight, kg
04/05 800 825 240 345 – 230 460 920 – – – 2000 – – 315
291-337
07 915 995 277,5 440 – 271 543 1085 – – – 2230 – – 400
360- 419
08 915 995 27 7,5 440 – 271 543 1085 – – – 2230 – – 400
369-428
11 655 119 9 324 1200 397 324 647 1295 – 935 551 2510 – – 500
552-646
12 655 1199 324 120 0 397 324 647 1295 – 935 551 2510 – – 500
574- 668
14 765 1400 1136 1300 450 400 1000 1395 298 188 200 2830 208 109 –
667-773
20 765 1400 1136 130 0 450 400 1000 1395 298 188 200 2830 208 109 –
703-809
25 835 1600 1336 1550 575 500 1200 1595 298 203 200 3220 193 94
– 905-1058
30 835 1600 1336 1550 575 500 1200 1595 298 203 200 3220 193 94
– 945-1098
