Swegon SILVER C RX - Page 60

GB.SILVERSK.170901
We reserve the right to alter specifications.
60 www.swegon.com
SD with coil heat exchanger
Thermal
efficiency
Nominal
flow rate
Effective
electric
power
SFPint
Face
velocity
Nominal
external
pressure
Internal
pressure drop
vent. comp.
Overall fan
efficiency
(EU) No
327/2011
Maximum
external
leaking rate
Maximum
internal
leakage
Energy
performance
of filters
Casing
sound power
level, LwA
% m³/s kW W/(m³/s) m/s Pa Pa % % % kWh/year dB(A)
Red Min. - low NRVU, BVU variable speed Run-around 74 0,20 0,02 168 0,3 0 24 65,4 - - - 25
Red Min. - high NRVU, BVU variable speed Run-around 74 0,20 0,76 171 0,3 1009 24 65,4 - - - 69
Yellow Average NRVU, BVU variable speed Run-around 68 0,75 0,71 554 1,1 350 162 65,4 - - - 55
Blue Max. - high NRVU, BVU variable speed Run-around 67 1,08 1,28 1016 1,6 331 284 65,4 1 0 2430 61
Red Max. - low NRVU, BVU variable speed Run-around 66 1,20 0,99 1508 1,8 0 335 65,4 - - - 64 Red Min. - low NRVU, BVU variable speed Run-around 74 0,20 0,02 163 0,3 0 22 65,4 - - - 25
Red Min. - high NRVU, BVU variable speed Run-around 74 0,20 0,76 163 0,3 1010 22 65,4 - - - 69
Yellow Average NRVU, BVU variable speed Run-around 68 0,75 0,69 502 1,1 350 146 65,4 - - - 55
Blue Max. - high NRVU, BVU variable speed Run-around 67 1,10 1,26 934 1,6 331 258 65,4 1 0 2540 62
Red Max. - low NRVU, BVU variable speed Run-around 66 1,20 0,93 1406 1,8 0 295 65,4 - - - 64 Red Min. - low NRVU, BVU variable speed Run-around 74 0,20 0,02 164 0,3 0 24 67,4 - - - 25
Red Min. - high NRVU, BVU variable speed Run-around 74 0,20 0,99 186 0,3 1215 24 67,4 - - - 71
Yellow Average NRVU, BVU variable speed Run-around 68 0,80 0,89 592 1,2 450 178 67,4 - - - 57
Blue Max. - high NRVU, BVU variable speed Run-around 66 1,20 1,61 1171 1,8 384 335 67,4 1 0 2910 64
Red Max. - low NRVU, BVU variable speed Run-around 66 1,20 0,94 1442 1,8 0 335 67,4 - - - 64
Red Min. - low NRVU, BVU variable speed Run-around 74 0,20 0,02 158 0,3 0 22 67,4 - - - 25
Red Min. - high NRVU, BVU variable speed Run-around 74 0,20 0,99 177 0,3 1216 22 67,4 - - - 71
Yellow Average NRVU, BVU variable speed Run-around 68 0,80 0,87 533 1,2 450 160 67,4 - - - 57
Blue Max. - high NRVU, BVU variable speed Run-around 66 1,20 1,61 1032 1,8 423 295 67,4 1 0 2910 64
Red Max. - low NRVU, BVU variable speed Run-around 66 1,20 0,89 1344 1,8 0 295 67,4 - - - 64
Red Min. - low NRVU, BVU variable speed Run-around 74 0,20 0,02 142 0,3 0 24 66,8 - - - 19
Red Min. - high NRVU, BVU variable speed Run-around 74 0,20 0,91 214 0,3 963 24 66,8 - - - 69
Yellow Average NRVU, BVU variable speed Run-around 68 0,90 0,74 700 1,3 250 214 66,8 - - - 54
Blue Max. - high NRVU, BVU variable speed Run-around 65 1,31 1,76 1247 1,9 396 388 66,8 1 0 3160 61
Red Max. - low NRVU, BVU variable speed Run-around 63 1,44 1,13 0 2,1 0 446 66,8 - - - 61
Red Min. - low NRVU, BVU variable speed Run-around 74 0,20 0,02 136 0,3 0 22 66,8 - - - 19
Red Min. - high NRVU, BVU variable speed Run-around 74 0,20 0,90 204 0,3 963 22 66,8 - - - 69
Yellow Average NRVU, BVU variable speed Run-around 68 0,90 0,70 623 1,3 250 192 66,8 - - - 54
Blue Max. - high NRVU, BVU variable speed Run-around 64 1,36 1,74 1145 2,0 391 358 66,8 1 0 3340 61
Red Max. - low NRVU, BVU variable speed Run-around 63 1,44 1,01 0 2,1 0 389 66,8 - - - 61
Red Min. - low NRVU, BVU variable speed Run-around 74 0,20 0,02 150 0,3 0 24 66,0 - - - 19
Red Min. - high NRVU, BVU variable speed Run-around 74 0,20 1,23 237 0,3 1189 24 66,0 - - - 72
Yellow Average NRVU, BVU variable speed Run-around 67 1,00 0,97 821 1,5 300 252 66,0 - - - 56
Blue Max. - high NRVU, BVU variable speed Run-around 63 1,44 2,41 1442 2,1 542 446 66,0 1 0 3710 63
Red Max. - low NRVU, BVU variable speed Run-around 63 1,44 1,13 1450 2,1 0 446 66,0 - - - 61 Red Min. - low NRVU, BVU variable speed Run-around 74 0,20 0,02 144 0,3 0 22 66,0 - - - 19
Red Min. - high NRVU, BVU variable speed Run-around 74 0,20 1,23 225 0,3 1191 22 66,0 - - - 72
Yellow Average NRVU, BVU variable speed Run-around 67 1,00 0,92 728 1,5 300 224 66,0 - - - 56
Blue Max. - high NRVU, BVU variable speed Run-around 63 1,43 2,41 1250 2,1 605 387 66,0 1 0 3690 63
Red Max. - low NRVU, BVU variable speed Run-around 63 1,43 1,00 1295 2,1 0 387 66,0 - - - 61
Red Min. - low NRVU, BVU variable speed Run-around 78 0,20 0,01 95 0,3 0 12 66,8 - - - 20
Red Min. - high NRVU, BVU variable speed Run-around 78 0,20 0,91 108 0,3 978 12 66,8 - - - 72
Yellow Average NRVU, BVU variable speed Run-around 66 1,10 0,82 431 1,4 300 136 66,8 - - - 57
Blue Max. - high NRVU, BVU variable speed Run-around 65 1,65 1,54 847 2,1 264 251 66,8 1 0 3200 65
Red Max. - low NRVU, BVU variable speed Run-around 64 1,80 1,26 1266 2,3 0 288 66,8 - - - 67
Red Min. - low NRVU, BVU variable speed Run-around 78 0,20 0,01 94 0,3 0 12 66,8 - - - 20
Red Min. - high NRVU, BVU variable speed Run-around 78 0,20 0,91 107 0,3 978 12 66,8 - - - 72
Yellow Average NRVU, BVU variable speed Run-around 66 1,10 0,81 423 1,4 300 134 66,8 - - - 57
Blue Max. - high NRVU, BVU variable speed Run-around 65 1,66 1,53 842 2,1 259 248 66,8 1 0 3250 65
Red Max. - low NRVU, BVU variable speed Run-around 64 1,80 1,25 1251 2,3 0 282 66,8 - - - 67
Red Min. - low NRVU, BVU variable speed Run-around 78 0,20 0,02 105 0,3 0 12 66,0 - - - 20
Red Min. - high NRVU, BVU variable speed Run-around 78 0,20 1,23 119 0,3 1205 12 66,0 - - - 74
Yellow Average NRVU, BVU variable speed Run-around 66 1,20 1,13 495 1,5 400 156 66,0 - - - 59
Blue Max. - high NRVU, BVU variable speed Run-around 64 1,80 2,13 953 2,3 383 288 66,0 7 0 3710 67
Red Max. - low NRVU, BVU variable speed Run-around 64 1,80 1,24 1246 2,3 0 288 66,0 - - - 67
Red Min. - low NRVU, BVU variable speed Run-around 78 0,20 0,02 105 0,3 0 12 66,0 - - - 20
Red Min. - high NRVU, BVU variable speed Run-around 78 0,20 1,23 118 0,3 1205 12 66,0 - - - 74
Yellow Average NRVU, BVU variable speed Run-around 66 1,20 1,13 486 1,5 400 153 66,0 - - - 59
Blue Max. - high NRVU, BVU variable speed Run-around 64 1,80 2,13 931 2,3 389 282 66,0 7 0 3710 67
Red Max. - low NRVU, BVU variable speed Run-around 64 1,80 1,23 1231 2,3 0 282 66,0 - - - 67 Red Min. - low NRVU, BVU variable speed Run-around 73 0,30 0,02 88 0,4 0 21 66,7 - - - 19
Red Min. - high NRVU, BVU variable speed Run-around 73 0,30 1,32 184 0,4 983 21 66,7 - - - 68
Yellow Average NRVU, BVU variable speed Run-around 65 1,60 1,33 756 2,0 250 241 66,7 - - - 57
Blue Max. - high NRVU, BVU variable speed Run-around 64 2,14 2,72 1208 2,7 368 376 66,7 1 0 4990 63
Red Max. - low NRVU, BVU variable speed Run-around 63 2,25 1,71 1400 2,8 0 408 66,7 - - - 62 Red Min. - low NRVU, BVU variable speed Run-around 73 0,30 0,02 87 0,4 0 21 66,7 - - - 19 Red Min. - high NRVU, BVU variable speed Run-around 73 0,30 1,32 182 0,4 983 21 66,7 - - - 68
Yellow Average NRVU, BVU variable speed Run-around 65 1,60 1,32 739 2,0 250 236 66,7 - - - 57
Blue Max. - high NRVU, BVU variable speed Run-around 64 2,15 2,71 1188 2,7 367 370 66,7 1 0 5050 63
Red Max. - low NRVU, BVU variable speed Run-around 63 2,26 1,68 1376 2,8 0 399 66,7 - - - 62 Red Min. - low NRVU, BVU variable speed Run-around 73 0,30 0,02 117 0,4 0 21 65,7 - - - 19
Red Min. - high NRVU, BVU variable speed Run-around 73 0,30 1,79 202 0,4 1213 21 65,7 - - - 70
Yellow Average NRVU, BVU variable speed Run-around 65 1,70 1,64 840 2,1 300 264 65,7 - - - 59
Blue Max. - high NRVU, BVU variable speed Run-around 63 2,25 3,73 1304 2,8 581 409 65,7 1 0 5470 65
Red Max. - low NRVU, BVU variable speed Run-around 63 2,24 1,70 1402 2,8 0 405 65,7 - - - 62 Red Min. - low NRVU, BVU variable speed Run-around 73 0,30 0,02 116 0,4 0 21 65,7 - - - 19
Red Min. - high NRVU, BVU variable speed Run-around 73 0,30 1,79 200 0,4 1213 21 65,7 - - - 70
Yellow Average NRVU, BVU variable speed Run-around 65 1,70 1,62 821 2,1 300 259 65,7 - - - 59
Blue Max. - high NRVU, BVU variable speed Run-around 63 2,25 3,73 1271 2,8 592 399 65,7 5 0 5470 65
Red Max. - low NRVU, BVU variable speed Run-around 63 2,25 1,69 1389 2,8 0 399 65,7 - - - 62 Red Min. - low NRVU, BVU variable speed Run-around 77 0,30 0,01 62 0,3 0 13 66,7 - - - 18
Red Min. - high NRVU, BVU variable speed Run-around 77 0,30 1,32 114 0,3 992 13 66,7 - - - 68
Yellow Average NRVU, BVU variable speed Run-around 66 1,60 1,18 425 1,6 300 136 66,7 - - - 57
Blue Max. - high NRVU, BVU variable speed Run-around 64 2,77 2,18 1330 2,7 27 312 66,7 6 0 8910 66
Red Max. - low NRVU, BVU variable speed Run-around 64 2,77 2,09 1376 2,7 0 312 66,7 - - - 66 Red Min. - low NRVU, BVU variable speed Run-around 77 0,30 0,01 62 0,3 0 13 66,7 - - - 18
Red Min. - high NRVU, BVU variable speed Run-around 77 0,30 1,32 112 0,3 992 13 66,7 - - - 68
Yellow Average NRVU, BVU variable speed Run-around 66 1,60 1,17 414 1,6 300 132 66,7 - - - 57
Blue Max. - high NRVU, BVU variable speed Run-around 64 2,78 2,16 1307 2,7 28 302 66,7 6 0 9090 66
Red Max. - low NRVU, BVU variable speed Run-around 64 2,78 2,08 1357 2,7 0 302 66,7 - - - 66 Red Min. - low NRVU, BVU variable speed Run-around 77 0,30 0,02 77 0,3 0 13 65,7 - - - 18 Red Min. - high NRVU, BVU variable speed Run-around 77 0,30 1,79 125 0,3 1222 13 65,7 - - - 70
Yellow Average NRVU, BVU variable speed Run-around 66 1,80 1,72 515 1,8 400 162 65,7 - - - 59
Blue Max. - high NRVU, BVU variable speed Run-around 64 2,74 3,35 1030 2,7 370 306 65,7 1 0 6890 67
Red Max. - low NRVU, BVU variable speed Run-around 64 2,80 2,09 1363 2,7 0 317 65,7 - - - 66
Red Min. - low NRVU, BVU variable speed Run-around 77 0,30 0,02 77 0,3 0 13 65,7 - - - 18 Red Min. - high NRVU, BVU variable speed Run-around 77 0,30 1,79 124 0,3 1222 13 65,7 - - - 70
Yellow Average NRVU, BVU variable speed Run-around 66 1,80 1,71 501 1,8 400 158 65,7 - - - 59
Blue Max. - high NRVU, BVU variable speed Run-around 64 2,75 3,34 1005 2,7 373 298 65,7 1 0 6950 67
Red Max. - low NRVU, BVU variable speed Run-around 64 2,80 2,05 1337 2,7 0 306 65,7 - - - 66 Red Min. - low NRVU, BVU variable speed Run-around 72 0,50 0,04 97 0,5 0 26 65,2 - - - 25
Red Min. - high NRVU, BVU variable speed Run-around 72 0,50 2,29 212 0,5 1090 26 65,2 - - - 70
Yellow Average NRVU, BVU variable speed Run-around 65 2,20 1,78 696 2,2 250 219 65,2 - - - 58
Blue Max. - high NRVU, BVU variable speed Run-around 63 3,31 4,51 1345 3,2 370 410 65,2 1 0 9370 66
Red Max. - low NRVU, BVU variable speed Run-around 63 3,26 2,48 1410 3,2 0 401 65,2 - - - 64 Red Min. - low NRVU, BVU variable speed Run-around 72 0,50 0,04 96 0,5 0 26 65,2 - - - 25
Red Min. - high NRVU, BVU variable speed Run-around 72 0,50 2,29 209 0,5 1090 26 65,2 - - - 70
Yellow Average NRVU, BVU variable speed Run-around 65 2,20 1,75 674 2,2 250 212 65,2 - - - 58
Blue Max. - high NRVU, BVU variable speed Run-around 63 3,35 4,49 1314 3,3 367 400 65,2 1 0 9550 66
Red Max. - low NRVU, BVU variable speed Run-around 63 3,31 2,51 1409 3,2 0 394 65,2 - - - 64 Red Min. - low NRVU, BVU variable speed Run-around 72 0,50 0,04 100 0,5 0 26 67,2 - - - 25
Red Min. - high NRVU, BVU variable speed Run-around 72 0,50 2,74 225 0,5 1235 26 67,2 - - - 72
Yellow Average NRVU, BVU variable speed Run-around 65 2,40 2,29 800 2,3 300 250 67,2 - - - 60
Blue Max. - high NRVU, BVU variable speed Run-around 63 3,40 5,53 1404 3,3 511 426 67,2 1 0 9860 67
Red Max. - low NRVU, BVU variable speed Run-around 63 3,26 2,48 1412 3,2 0 399 67,2 - - - 64
Red Min. - low NRVU, BVU variable speed Run-around 72 0,50 0,04 99 0,5 0 26 67,2 - - - 25 Red Min. - high NRVU, BVU variable speed Run-around 72 0,50 2,74 222 0,5 1235 26 67,2 - - - 72
Yellow Average NRVU, BVU variable speed Run-around 65 2,40 2,25 773 2,3 300 242 67,2 - - - 60
Blue Max. - high NRVU, BVU variable speed Run-around 63 3,45 5,49 1384 3,4 494 420 67,2 1 0 10100 67
Red Max. - low NRVU, BVU variable speed Run-around 63 3,30 2,50 1410 3,2 0 392 67,2 - - - 64 Red Min. - low NRVU, BVU variable speed Run-around 75 0,50 0,02 66 0,3 0 15 65,2 - - - 23
Red Min. - high NRVU, BVU variable speed Run-around 75 0,50 2,29 119 0,3 1106 15 65,2 - - - 70
Yellow Average NRVU, BVU variable speed Run-around 66 2,40 2,01 460 1,4 350 145 65,2 - - - 59
Blue Max. - high NRVU, BVU variable speed Run-around 65 3,84 4,07 1076 2,3 248 298 65,2 1 0 8360 67
Red Max. - low NRVU, BVU variable speed Run-around 65 3,92 3,11 1445 2,3 0 307 65,2 - - - 67 Red Min. - low NRVU, BVU variable speed Run-around 75 0,50 0,02 66 0,3 0 14 65,2 - - - 23 Red Min. - high NRVU, BVU variable speed Run-around 75 0,50 2,29 117 0,3 1106 14 65,2 - - - 70
Yellow Average NRVU, BVU variable speed Run-around 66 2,40 1,98 438 1,4 350 138 65,2 - - - 59
Blue Max. - high NRVU, BVU variable speed Run-around 65 3,86 4,06 1030 2,3 250 281 65,2 1 0 8550 67
Red Max. - low NRVU, BVU variable speed Run-around 64 3,98 3,17 1445 2,4 0 296 65,2 - - - 68 Red Min. - low NRVU, BVU variable speed Run-around 75 0,50 0,02 66 0,3 0 15 67,2 - - - 23 Red Min. - high NRVU, BVU variable speed Run-around 75 0,50 2,74 127 0,3 1251 15 67,2 - - - 72
Yellow Average NRVU, BVU variable speed Run-around 66 2,60 2,70 523 1,5 450 163 67,2 - - - 61
Blue Max. - high NRVU, BVU variable speed Run-around 64 4,00 5,02 1110 2,4 354 316 67,2 1 0 8750 68
Red Max. - low NRVU, BVU variable speed Run-around 65 3,91 3,10 1445 2,3 0 305 67,2 - - - 67 Red Min. - low NRVU, BVU variable speed Run-around 75 0,50 0,02 65 0,3 0 14 67,2 - - - 23
Red Min. - high NRVU, BVU variable speed Run-around 75 0,50 2,74 124 0,3 1251 14 67,2 - - - 72
Yellow Average NRVU, BVU variable speed Run-around 66 2,60 2,67 496 1,5 450 155 67,2 - - - 61
Blue Max. - high NRVU, BVU variable speed Run-around 64 4,00 5,02 1043 2,4 373 297 67,2 1 0 8750 68
Red Max. - low NRVU, BVU variable speed Run-around 65 3,97 3,16 1445 2,3 0 294 67,2 - - - 68
Red Min. - low NRVU, BVU variable speed Run-around 70 0,75 0,04 83 0,4 0 26 70,5 - - - 26
Red Min. - high NRVU, BVU variable speed Run-around 70 0,75 2,30 190 0,4 822 26 70,5 - - - 69
Yellow Average NRVU, BVU variable speed Run-around 66 2,70 1,94 546 1,6 250 173 70,5 - - - 58
Blue Max. - high NRVU, BVU variable speed Run-around 64 4,11 4,33 1057 2,4 282 330 70,5 1 0 8400 64
Red Max. - low NRVU, BVU variable speed Run-around 63 4,78 3,64 1410 2,8 0 417 70,5 - - - 65
Red Min. - low NRVU, BVU variable speed Run-around 70 0,75 0,04 81 0,4 0 26 70,5 - - - 26
Red Min. - high NRVU, BVU variable speed Run-around 70 0,75 2,31 185 0,4 823 26 70,5 - - - 69
Yellow Average NRVU, BVU variable speed Run-around 66 2,70 1,90 517 1,6 250 164 70,5 - - - 57
Blue Max. - high NRVU, BVU variable speed Run-around 64 4,14 4,31 1004 2,4 292 314 70,5 1 0 8510 64
Red Max. - low NRVU, BVU variable speed Run-around 63 4,88 3,65 1382 2,9 0 402 70,5 - - - 66
Red Min. - low NRVU, BVU variable speed Run-around 70 0,75 0,04 83 0,4 0 26 69,2 - - - 26 Red Min. - high NRVU, BVU variable speed Run-around 70 0,75 3,57 217 0,4 1128 26 69,2 - - - 72
Yellow Average NRVU, BVU variable speed Run-around 65 3,30 3,30 751 1,9 350 235 69,2 - - - 61
Blue Max. - high NRVU, BVU variable speed Run-around 63 4,85 7,02 1404 2,9 403 426 69,2 1 0 11800 67
Red Max. - low NRVU, BVU variable speed Run-around 63 4,77 3,64 1409 2,8 0 417 69,2 - - - 65
Red Min. - low NRVU, BVU variable speed Run-around 70 0,75 0,04 81 0,4 0 26 69,2 - - - 26 Red Min. - high NRVU, BVU variable speed Run-around 70 0,75 3,57 211 0,4 1128 26 69,2 - - - 72
Yellow Average NRVU, BVU variable speed Run-around 65 3,30 3,23 707 1,9 350 222 69,2 - - - 61
Blue Max. - high NRVU, BVU variable speed Run-around 63 4,91 6,98 1338 2,9 407 406 69,2 1 0 12100 68
Red Max. - low NRVU, BVU variable speed Run-around 63 4,91 3,72 1401 2,9 0 406 69,2 - - - 66
Red Min. - low NRVU, BVU variable speed Run-around 76 0,60 0,03 61 0,2 0 12 66,7 - - - 21
Red Min. - high NRVU, BVU variable speed Run-around 76 0,60 2,65 104 0,2 994 12 66,7 - - - 71
Yellow Average NRVU, BVU variable speed Run-around 66 3,10 2,49 407 1,2 350 130 66,7 - - - 60
Blue Max. - high NRVU, BVU variable speed Run-around 65 5,02 4,89 930 1,9 255 270 66,7 1 0 10100 68
Red Max. - low NRVU, BVU variable speed Run-around 65 5,54 4,20 1385 2,1 0 315 66,7 - - - 69
Red Min. - low NRVU, BVU variable speed Run-around 76 0,60 0,03 61 0,2 0 12 66,7 - - - 21 Red Min. - high NRVU, BVU variable speed Run-around 76 0,60 2,65 102 0,2 995 12 66,7 - - - 71
Yellow Average NRVU, BVU variable speed Run-around 66 3,10 2,45 383 1,2 350 122 66,7 - - - 60
Blue Max. - high NRVU, BVU variable speed Run-around 65 5,04 4,86 876 1,9 264 252 66,7 1 0 10300 68
Red Max. - low NRVU, BVU variable speed Run-around 65 5,59 4,15 1346 2,1 0 295 66,7 - - - 69
Red Min. - low NRVU, BVU variable speed Run-around 76 0,60 0,03 74 0,2 0 12 65,7 - - - 21 Red Min. - high NRVU, BVU variable speed Run-around 76 0,60 3,57 115 0,2 1224 12 65,7 - - - 73
Yellow Average NRVU, BVU variable speed Run-around 67 3,30 3,29 452 1,3 450 142 65,7 - - - 62
Blue Max. - high NRVU, BVU variable speed Run-around 65 5,60 6,57 1098 2,1 319 320 65,7 1 0 12300 70
Red Max. - low NRVU, BVU variable speed Run-around 65 5,60 4,20 1372 2,1 0 320 65,7 - - - 69 Red Min. - low NRVU, BVU variable speed Run-around 76 0,60 0,03 73 0,2 0 12 65,7 - - - 21
Red Min. - high NRVU, BVU variable speed Run-around 76 0,60 3,57 112 0,2 1225 12 65,7 - - - 73
Yellow Average NRVU, BVU variable speed Run-around 67 3,30 3,24 425 1,3 450 134 65,7 - - - 62
Blue Max. - high NRVU, BVU variable speed Run-around 65 5,60 6,57 1014 2,1 343 296 65,7 1 0 12300 70
Red Max. - low NRVU, BVU variable speed Run-around 65 5,60 4,04 1312 2,1 0 296 65,7 - - - 69 Red Min. - low NRVU, BVU variable speed Run-around 70 1,00 0,05 73 0,4 0 25 65,2 - - - 27
Red Min. - high NRVU, BVU variable speed Run-around 70 1,00 4,65 208 0,4 1102 25 65,2 - - - 73
Yellow Average NRVU, BVU variable speed Run-around 66 4,30 3,80 683 1,6 300 213 65,2 - - - 61
Blue Max. - high NRVU, BVU variable speed Run-around 64 6,63 9,10 1361 2,5 373 416 65,2 1 0 16300 69
Red Max. - low NRVU, BVU variable speed Run-around 64 6,58 5,05 1419 2,5 0 412 65,2 - - - 67 Red Min. - low NRVU, BVU variable speed Run-around 70 1,00 0,05 70 0,4 0 25 65,2 - - - 27
Red Min. - high NRVU, BVU variable speed Run-around 70 1,00 4,65 201 0,4 1103 25 65,2 - - - 73
Yellow Average NRVU, BVU variable speed Run-around 66 4,30 3,69 636 1,6 300 199 65,2 - - - 61
Blue Max. - high NRVU, BVU variable speed Run-around 63 6,77 8,99 1291 2,6 366 394 65,2 1 0 16900 69
Red Max. - low NRVU, BVU variable speed Run-around 63 6,81 5,18 1410 2,6 0 399 65,2 - - - 68 Red Min. - low NRVU, BVU variable speed Run-around 70 1,00 0,08 116 0,4 0 25 67,4 - - - 27
Red Min. - high NRVU, BVU variable speed Run-around 70 1,00 7,13 237 0,4 1492 25 67,4 - - - 76
Yellow Average NRVU, BVU variable speed Run-around 66 4,50 4,81 729 1,7 400 228 67,4 - - - 63
Blue Max. - high NRVU, BVU variable speed Run-around 64 6,70 14,91 1413 2,5 859 423 67,4 1 0 16900 71
Red Max. - low NRVU, BVU variable speed Run-around 64 6,49 4,99 1422 2,5 0 403 67,4 - - - 67
Red Min. - low NRVU, BVU variable speed Run-around 70 1,00 0,08 112 0,4 0 25 67,4 - - - 27
Red Min. - high NRVU, BVU variable speed Run-around 70 1,00 7,13 230 0,4 1493 25 67,4 - - - 76
Yellow Average NRVU, BVU variable speed Run-around 66 4,50 4,69 677 1,7 400 212 67,4 - - - 63
Blue Max. - high NRVU, BVU variable speed Run-around 63 6,96 14,91 1376 2,6 821 412 67,4 1 0 18100 71
Red Max. - low NRVU, BVU variable speed Run-around 64 6,72 5,12 1415 2,5 0 391 67,4 - - - 67
Red Min. - low NRVU, BVU variable speed Run-around 71 1,00 0,04 57 0,3 0 20 65,2 - - - 26
Red Min. - high NRVU, BVU variable speed Run-around 71 1,00 4,65 160 0,3 1109 20 65,2 - - - 73
Yellow Average NRVU, BVU variable speed Run-around 66 4,80 4,50 639 1,6 350 200 65,2 - - - 63
Blue Max. - high NRVU, BVU variable speed Run-around 64 7,25 8,56 1266 2,4 283 378 65,2 1 0 15200 69
Red Max. - low NRVU, BVU variable speed Run-around 64 7,27 5,60 1422 2,4 0 381 65,2 - - - 69
Red Min. - low NRVU, BVU variable speed Run-around 71 1,00 0,04 56 0,3 0 19 65,2 - - - 26 Red Min. - high NRVU, BVU variable speed Run-around 71 1,00 4,65 156 0,3 1110 19 65,2 - - - 73
Yellow Average NRVU, BVU variable speed Run-around 66 4,80 4,43 609 1,6 350 191 65,2 - - - 63
Blue Max. - high NRVU, BVU variable speed Run-around 64 7,31 8,50 1218 2,4 284 362 65,2 1 0 15500 70
Red Max. - low NRVU, BVU variable speed Run-around 64 7,42 5,70 1419 2,4 0 371 65,2 - - - 69
Red Min. - low NRVU, BVU variable speed Run-around 71 1,00 0,06 88 0,3 0 20 67,4 - - - 26 Red Min. - high NRVU, BVU variable speed Run-around 71 1,00 7,13 182 0,3 1499 20 67,4 - - - 76
Yellow Average NRVU, BVU variable speed Run-around 66 5,20 5,92 721 1,7 450 227 67,4 - - - 65
Blue Max. - high NRVU, BVU variable speed Run-around 63 7,70 14,64 1409 2,5 661 417 67,4 1 0 17200 72
Red Max. - low NRVU, BVU variable speed Run-around 64 7,19 5,55 1427 2,3 0 374 67,4 - - - 69 Red Min. - low NRVU, BVU variable speed Run-around 71 1,00 0,06 86 0,3 0 19 67,4 - - - 26
Red Min. - high NRVU, BVU variable speed Run-around 71 1,00 7,13 179 0,3 1500 19 67,4 - - - 76
Yellow Average NRVU, BVU variable speed Run-around 66 5,20 5,83 686 1,7 450 216 67,4 - - - 65
Blue Max. - high NRVU, BVU variable speed Run-around 63 7,84 14,54 1370 2,6 642 403 67,4 1 0 17900 72
Red Max. - low NRVU, BVU variable speed Run-around 64 7,34 5,64 1419 2,4 0 364 67,4 - - - 69
Red Min. - low NRVU, BVU variable speed Run-around 65 1,50 0,09 94 0,5 0 36 69,2 - - - 31
Red Min. - high NRVU, BVU variable speed Run-around 65 1,50 7,40 298 0,5 1137 36 69,2 - - - 75
Yellow Average NRVU, BVU variable speed Run-around 65 6,00 6,01 909 2,0 300 283 69,2 - - - 64
Blue Max. - high NRVU, BVU variable speed Run-around 63 7,79 14,32 1405 2,5 640 424 69,2 1 0 17200 70
Red Max. - low NRVU, BVU variable speed Run-around 63 7,86 5,90 0 2,6 0 430 69,2 - - - 65
Red Min. - low NRVU, BVU variable speed Run-around 65 1,50 0,09 91 0,5 0 35 69,2 - - - 31
Red Min. - high NRVU, BVU variable speed Run-around 65 1,50 7,39 291 0,5 1137 35 69,2 - - - 75
Yellow Average NRVU, BVU variable speed Run-around 65 6,00 5,86 860 2,0 300 268 69,2 - - - 63
Blue Max. - high NRVU, BVU variable speed Run-around 63 7,86 14,34 1340 2,6 652 405 69,2 1 0 17500 70
Red Max. - low NRVU, BVU variable speed Run-around 63 7,86 5,59 1313 2,6 0 405 69,2 - - - 65
Red Min. - low NRVU, BVU variable speed Run-around 65 1,50 0,14 144 0,5 0 36 68,5 - - - 31
Red Min. - high NRVU, BVU variable speed Run-around 65 1,50 10,50 320 0,5 1520 36 68,5 - - - 78
Yellow Average NRVU, BVU variable speed Run-around 65 6,30 7,67 995 2,1 400 305 68,5 - - - 65
Blue Max. - high NRVU, BVU variable speed Run-around 63 7,70 20,05 1410 2,5 1077 417 68,5 1 0 17200 73
Red Max. - low NRVU, BVU variable speed Run-around 63 7,80 5,94 1403 2,5 0 424 68,5 - - - 65
Red Min. - low NRVU, BVU variable speed Run-around 65 1,50 0,14 140 0,5 0 35 68,5 - - - 31
Red Min. - high NRVU, BVU variable speed Run-around 65 1,50 10,50 311 0,5 1521 35 68,5 - - - 78
Yellow Average NRVU, BVU variable speed Run-around 65 6,30 7,49 941 2,1 400 289 68,5 - - - 65
Blue Max. - high NRVU, BVU variable speed Run-around 63 7,82 20,22 1351 2,6 1091 402 68,5 1 0 17600 73
Red Max. - low NRVU, BVU variable speed Run-around 63 7,82 5,66 1335 2,6 0 402 68,5 - - - 65 Red Min. - low NRVU, BVU variable speed Run-around 70 1,50 0,04 40 0,3 0 18 69,2 - - - 28
Red Min. - high NRVU, BVU variable speed Run-around 70 1,50 7,40 152 0,3 1158 18 69,2 - - - 75
Yellow Average NRVU, BVU variable speed Run-around 66 7,50 6,88 607 1,5 350 192 69,2 - - - 65
Blue Max. - high NRVU, BVU variable speed Run-around 64 11,21 13,02 1237 2,3 268 357 69,2 1 0 24300 72
Red Max. - low NRVU, BVU variable speed Run-around 64 11,17 8,71 1440 2,3 0 355 69,2 - - - 71
Red Min. - low NRVU, BVU variable speed Run-around 70 1,50 0,04 39 0,3 0 18 69,2 - - - 28
Red Min. - high NRVU, BVU variable speed Run-around 70 1,50 7,40 149 0,3 1158 18 69,2 - - - 75
Yellow Average NRVU, BVU variable speed Run-around 66 7,50 6,78 579 1,5 350 183 69,2 - - - 65
Blue Max. - high NRVU, BVU variable speed Run-around 64 11,28 12,95 1187 2,3 274 340 69,2 1 0 24700 72
Red Max. - low NRVU, BVU variable speed Run-around 64 11,36 8,87 1436 2,3 0 344 69,2 - - - 72
Red Min. - low NRVU, BVU variable speed Run-around 70 1,50 0,06 61 0,3 0 18 68,5 - - - 28 Red Min. - high NRVU, BVU variable speed Run-around 70 1,50 10,50 163 0,3 1541 18 68,5 - - - 78
Yellow Average NRVU, BVU variable speed Run-around 66 7,50 8,26 621 1,5 450 192 68,5 - - - 66
Blue Max. - high NRVU, BVU variable speed Run-around 64 12,00 20,88 1327 2,5 597 396 68,5 1 0 26600 74
Red Max. - low NRVU, BVU variable speed Run-around 64 11,22 8,74 1435 2,3 0 357 68,5 - - - 71
Red Min. - low NRVU, BVU variable speed Run-around 70 1,50 0,06 59 0,3 0 18 68,5 - - - 28 Red Min. - high NRVU, BVU variable speed Run-around 70 1,50 10,50 160 0,3 1541 18 68,5 - - - 78
Yellow Average NRVU, BVU variable speed Run-around 66 7,50 8,15 593 1,5 450 183 68,5 - - - 66
Blue Max. - high NRVU, BVU variable speed Run-around 64 12,00 20,88 1251 2,5 620 374 68,5 1 0 26600 74
Red Max. - low NRVU, BVU variable speed Run-around 64 11,42 8,88 1429 2,3 0 346 68,5 - - - 72
Red Min. - low NRVU, BVU variable speed Run-around 64 2,50 0,19 119 0,5 0 38 69,2 - - - 35
Red Min. - high NRVU, BVU variable speed Run-around 64 2,50 10,94 290 0,5 1085 38 69,2 - - - 77
Yellow Average NRVU, BVU variable speed Run-around 65 9,30 9,40 887 1,9 300 267 69,2 - - - 66
Blue Max. - high NRVU, BVU variable speed Run-around 64 12,30 21,52 1413 2,5 560 411 69,2 1 0 28700 72
Red Max. - low NRVU, BVU variable speed Run-around 63 12,32 9,44 1415 2,5 0 414 69,2 - - - 68
Red Min. - low NRVU, BVU variable speed Run-around 64 2,50 0,19 116 0,5 0 37 69,2 - - - 35
Red Min. - high NRVU, BVU variable speed Run-around 64 2,50 10,95 283 0,5 1087 37 69,2 - - - 77
Yellow Average NRVU, BVU variable speed Run-around 65 9,30 9,19 842 1,9 300 253 69,2 - - - 66
Blue Max. - high NRVU, BVU variable speed Run-around 63 12,72 21,50 1404 2,6 529 410 69,2 1 0 30500 72
Red Max. - low NRVU, BVU variable speed Run-around 63 12,67 9,64 1403 2,6 0 406 69,2 - - - 68
Red Min. - low NRVU, BVU variable speed Run-around 64 2,50 0,26 157 0,5 0 38 68,5 - - - 35
Red Min. - high NRVU, BVU variable speed Run-around 64 2,50 16,10 324 0,5 1447 38 68,5 - - - 80
Yellow Average NRVU, BVU variable speed Run-around 65 10,00 12,61 1017 2,0 400 299 68,5 - - - 68
Blue Max. - high NRVU, BVU variable speed Run-around 64 12,03 30,68 1420 2,5 985 398 68,5 1 0 28500 75
Red Max. - low NRVU, BVU variable speed Run-around 64 11,87 9,16 1425 2,4 0 390 68,5 - - - 67
Red Min. - low NRVU, BVU variable speed Run-around 64 2,50 0,25 153 0,5 0 37 68,5 - - - 35
Red Min. - high NRVU, BVU variable speed Run-around 64 2,50 16,10 315 0,5 1448 37 68,5 - - - 80
Yellow Average NRVU, BVU variable speed Run-around 65 10,00 12,34 964 2,0 400 284 68,5 - - - 68
Blue Max. - high NRVU, BVU variable speed Run-around 63 12,67 31,33 1397 2,6 983 406 68,5 1 0 30400 75
Red Max. - low NRVU, BVU variable speed Run-around 64 12,16 9,32 1417 2,5 0 382 68,5 - - - 67
120
1
Duct
Full face
2
Duct
Full face
100
1
Duct
Full face
2
Duct
Full face
80
1
Duct
Full face
2
Duct
Full face
70
1
Duct
Full face
2
Duct
Full face
60
1
Duct
Full face
2
Duct
Full face
50
1
Duct
Full face
2
Duct
Full face
40
1
Duct
Full face
2
Duct
Full face
35
1
Duct
Full face
2
Duct
Full face
30
1
Duct
Full face
2
Duct
Full face
25
1
Duct
Full face
2
Duct
Full face
1
Duct
Full face
2
Duct
Full face
20
1
Duct
Full face
2
Duct
Full face
14
1
Duct
Full face
2
Duct
Full face
Working point Part of information requirements for NRVU according to Regulation (EU) No 1253/2014
In and outlet
connections
Colour Remark
AHU
type
Type of
drive
Type of
HRS
Size
Motor
option
12
1
Duct
Full face
2
Duct
Full face
11
