7.2
Fuse Install and Replace
Insert the power plug of the embroidery machine. If power remains off when pressing the power switch, take
actions following the below direction. Check the fuse location as in <Fig. 7.2.2-1> and replace the fuse with a new
one.
1) Power Fuse (3-phase)
[Fig. 7.2-1]
<Control Box Front>
Fuse Specifications: 250V, 30A, 31.8mm
Fuse Q’ty: 3 (single-phase: 2 units)
