SWF K Series User Manual

55--1199
5.3.3 CF Card Input
This function is to import the embroidery design files saved in the C/F card to the OP Box.
Connect a C/F card containing embroidery design files to the C/F card reader and insert the USB plug of the C/F
card reader into the USB port of the OP Box.
When “C/F Card”is chosen in <Fig. 5.3.0-1>, <Fig. 5.3.3-1> appears.
Use , in <Fig. 5.3.3-1> to move to the folder which has embroidery designs.
When is pressed, the design files in the chosen folder are displayed as in <Fig. 5.3.3-2>.
To move to the upper-level folder, select the “”folder on the left-hand side.
DIR/FILE
F3
F2
F1
[Fig. 5.3.3-1]
[Fig. 5.3.3-2]
