22--11
2
Basic Steps Before Starting Embroidery
2.1
Embroidery Machine Power-On
[Fig 2.1-1]
① Insert the power plug of the embroidery machine into the outlet
② Turn on the main power switch (‘ON’)
③ Turn on the operation switch, and then the LCD screen of the OP Box is turned on and the operating program is
displayed on the screen.
④ Use the frame move keys to check the appropriateness of the frame motion. Check the basic motions by referring
to ‘5.8.3 Motion Test’.
[ Warning ]
Make sure to pull off the power plug before A/S service activities begin.
Emergency Switch
Emergency Switch
Operation Switch
Main Power
Switch
※※
SB, Multi-Head E-Series Embroidery Machine
