5.7.2 Design Divide
This function is to save two different designs of the desired part of the design chosen. The designs can be divided
by color or needle number.
<Fig. 5.7.2-1> will appear when Stitch Separation is pressed in <Fig. 5.7.0-1>. The design on the left side is the
design chosen during design call. The screen on the right is to show the remaining part of the design, which was
separated from the chosen design.
[Fig. 5.7.2-1]
: It sets the number of stitches to be separated from the design.
: This button can be used after the + color button is pressed, and has the opposite function of the ＋
color button. When this button is pressed, color is added to the original design (Same function as
“Color－ (Number key “1”) in “5.5.4 Fastview”).
: When this button is pressed, only one color is left on the left, and all colors are moved to the right
side. (Same function as “Color＋ (Number key “2”) as in “5.5.4 Fastview”.)
: The separate two designs are saved in the memory.
