[Exercise 5.4.5-1] Design start position - X : 500, Y : 300
Offset middle position - X : 1000, Y : 1000
Stop position after design completion (offset) - X : 1500, Y : 1700
Make the above settings.
Press “Frame Offset Setting” on the setting menu.
Then <Fig. 5.4.5-1> appears.
Use , to move to “Design Start Point” and press .
It will enable the design start point.
Set the X, Y values for the frame location by using the frame move buttons.
Use
,
to move to the “Offset Middle Point” and select . Then the offset mid-
position will be enabled.
Set the X, Y values for the frame location by using the frame move buttons.
Press
,
to move to “Design Offset Point” and then press .
Then, the stop position becomes enabled after the embroidery work is completed.
Set the X, Y values for the frame location by using the frame move buttons.
Press .
