55--6655
(3) Trim Set
There are three trimming-related settings: Trimming start angle setting, main-shaft start acceleration speed
setting, and bartack length setting for trimming.
① Trim Angle Setting
This function is to change the main shaft angle when the trimming motor feed begins.
– The default is 0。, and the value can be adjusted from -5。to 5。by the unit of 1。.
② Accelation
This function is to set the time taken for the machine to reach the embroidery speed after the machine started
operating at the inching speed.
– The default is Normal. Either Normal(0) or Slow(1) can be chosen.
embroidery speed
inching speed
Time
start
t
[Fig. 5.4.7-6]
To Next Page
