Equipment Details
50
CRAMER LIQUID GAS
BUILT-IN-HOB
OPERATING INSTRUCTIONS
Please read these operating instructions
carefully before using the appliance.
Validity
These operating instructions apply to the
following Cramer Built-in-Hob in the EK 2000
model range: EK-1101 to EK-1277, CE-1300
to CE-1414
Initial Operation of the Appliance
Open the gas- bottle valve.
Open the hob shut-off valve.
Turn the control knob of the relevant
burner from the off-position (0-mark)
anticlockwise to maximum (high flame).
Push the knob in and hold it in this
position.
Ignite the burner with a match or other
suitable ignition device.
If the burner ignites the knob can be
released after approximately 10 seconds.
The knob may now be set to the required
burner position.
High flame = maximum position
(depending from model: 2,0 kW; 1,6 kW
or 1,0 kW)
Low flame = minimum position
(ca 0,5 kW)
The entire process should be clearly
visible from above and not obstructed by
cooking utensils.
Switching off the Appliance
Turn the control knob to the off-position,
(0-mark) to extinguish the burner.
Close the hob shut-off valve.
Close the bottle valve during longer
periods of non-operation.
Action in Case of Faults
If a fault occurs the appliance must be
switched off (see above) and a specialist
consulted.
Correct Use of the Hob
Cooking Utensils
Care should be taken that utensils are
placed in the middle of the ring and that
flames do not rise above the rims.
Utensils with misshapen/distorted
bottoms must not be used.
Air Supply
Ventilation openings with a cross section
of a least 150 cm
2
are essential in the
room where the cooker is operated
during operation of the burner(s). (See
the instructions displayed above the
cooker).
The combustion air supply pipes should
be checked from time to time and
cleaned if necessary.
The burners must not be used as heaters.
WARNING: The burners must not be
operated during refuelling or in garages.
Instructions for Long Periods of Non-
Operation
Turn the knobs to the off-position
(0-mark).
Close the hob shut-off valve.
Close the bottle valve.
After a long period of non-operation the
appliance should be examined by a
specialist*
Care and Cleaning of the Appliance
A standard cleansing agent can be used
to clean the appliance.
Allow the appliance to cool before
cleaning.
To avoid damage, the outer surface of the
appliance should be cleaned using only a
damp cloth without the addition of
chemical or granular cleansing agents.
The burner head(s) must not be
dismantled when cleaning the appliance.
