Equipment Details
70
HEKI-2 ROOF LIGHT (SEITZ)
The lift/tilt roof light can be set in 3 positions
by means of pneumatic springs.
Position 1 lifts the pane 12mm without
allowing rain to enter the motorhome.
Position 2 sets the pane to a 150mm opening
and locks with a bar.
Position 3 opens the pane through 55°.
A fully adjustable flyscreen and black-out
screen are built into the inner frame. The
flyscreen can be drawn independently and
the black-out screen is variable for partial or
full black-out.
Forced ventilation functions via a brush lined
duct instead of a ventilated pane.
A cover hood can be fitted for winter
protection.
Heki-2 roof lights provide 13,200mm
2
of fixed
ventilation.
Close the roof light completely before driving.
Do not operate whilst the vehicle is moving.
Do not stand on the roof light.
Do not leave your vehicle whilst the roof light
is open.
THE OMNIVENT (12V) ROOFLIGHT
The Omnivent is a double glazed rooflight
constructed from a synthetic ultra-violet
screened material. Its side operating
mechanism allows a completely free central
opening with built-in fixed ventilation when
closed.
Red Switch = Mode of Operation
Induction (IN)
Expel (OUT)
Black Switch = Speed Control
1, 2 and 3
Omnivents give no fixed ventilation when set
on induction.
ASH FRAMED DOORS
In order to provide customers with the latest
designs of door furniture it is possible, due to
the use of natural wood, that warping may
IN
OFF
OUT
Heki-2 Roof Light
occur. This should not detract from the
correct functioning of items fitted in the
motorhome.
SHOWER
When using the shower, always ensure that
the shower curtain is fully drawn thus
avoiding water spray on unprotected areas.
