Equipment Details
53
Cassette C-200 S and C-200 CS
The toilet section of the C-200 S/C-200 SC
includes a rotatable bowl, a removable seat,
a control unit with a flush button and a waste
level warning device. Under the bowl, the
valve blade handle is located.
Preparing for Use
1. To remove holding tank, open the access
door. Pull retaining clip upwards (fig. 1).
2. Remove holding tank by pulling straight
out. When holding tank hits the stop, tilt
downwards slightly and remove (fig. 2).
3. Position tank vertically and swivel pour-
out spout upwards (fig. 3).
4. Remove the cap of pour-out spout. Add
required amount of toilet fluid through
pour-out spout. Add small amount of
water through spout to cover holding tank
bottom. Replace cap and return pour-out
spout to its original stored position (fig. 4).
Note: Hotter weather or longer
retention time may require additional
toilet fluid. Use only Thetford toilet fluid
to achieve the best results.
Caution: Never add toilet fluid directly
into toilet bowl.
5. Slide the holding tank into the vehicle
through access door (fig. 5).
6. Make sure the holding tank is secured by
the retaining clip. Close and lock access
door (fig. 6).
Operation
7. Turn the bowl in the most comfortable
position, when necessary (fig. 7)
8. Before using the toilet we recommend
adding some water to the bowl by
pressing the flush button. Flush will stop
when the button is released (fig. 8).
1 2
3 4
5 6
7 8
