6. CYLINDER H
E
AD/V
AL
VE
SYM
6-6
Remove cylinder head.
Caution
DISASSE
M
BL
Y CYLINDER
HEAD
Remove the fixed (bolt × 1), then remove the
camshaft.
Remove the valve rocker arm shaft.
Remove the valve rocker arm.
Loosen the nuts diagonally by 2-3
sequences.
Camshaft
145
147
