Sym Fiddle III 50 Service Manual

SYM 12. BODY COVER
12-1
MAINTENANCE INFORMATION........12-2
HANDLE COVER ...............................12-3
FRONT COVER..................................12-4
FRONT INNER BOX...........................12-5
BODY COVER/REAR CENTER
COVER/REAR FENDER ....................12-6
FRONT CENTER COVER.................. 12-8
LUGGAGE BOX ................................. 12-8
FLOOR PANEL .................................. 12-8
SIDE COVER ..................................... 12-9
UNDER COVER.................................12-10
Double Seat
F
ront
h
andle
cover
Under cover
Luggage box
Left side cover
Left body cover
Rear h
andle
cover
Floor panel
FR.
Inner
box
Right side cover
Right body
cover
Left up body cover
FR. Inner box lid
Under spoiler
F
ront cover
spoile
Center cover
Front fender
Center cover
RR. fender
RR. UP. center cover
Main cover
