Sym Fiddle III 50 Service Manual

SYM 16. ELECTRICAL EQUIPMENT
16-1
MECHANISM DIAGRAM ....................16-1
PRECAUTIONS IN OPERATION .......16-2
TROUBLE DIAGNOSIS......................16-4
CHARGING SYSTEM.........................16-5
IGNITION SYSTEM............................16-11
STARTING SYSTEM..........................16-14
METER ...............................................16-15
LIGHTS/BULBS..................................16-17
SWITCH .............................................16-19
FUEL UNIT .........................................16-22
MECHANISM DIAGRAM
Spark plug
Fuel unit
Ignition coil
Main switch
Starter magnetic
switch
Starter switch
Horn/turn signal
light/high & low
beam
Front stop switch
Rear stop switch
Auto by
-star
REG.REC
C.D.I
/
B
attery
/
fuse box
Winker relay
Horn
