5. Removal & Installation of Engine
5-4
Remove the air cleaner connection bolts (2 bolts).
Remove the air cleaner.
Remove the exhaust muffler (3 bolts, 2 nuts).
Drain out coolant, and remove coolant inlet hose.
Remove the coolant inlet hose and thermo-sensor
wire.
To this chapter contents
2 bolts
Inlet hose
Drain bolt
3 bolts
2 nuts
Thermo-sensor wire
Outlet hose
