Sym MaxSym 600i ABS Service Manual

5. Engine Removal
5-1
L
Precautions in Operation ......................5-1
Removal of Engine .................................5-2
Engine Installation ............................. 5-4
Precautions in Operation
 The engine has to be supported with special service tools that can be lifted or adjustable.
 The following parts can be serviced as engine mounted on frame.
 Carburetor.
 Cylinder head, cylinder, and piston.
 Driving pulley, driving belt, clutch, and driving disc assembly.
 Final gear reduction mechanism.
Specification
Item
Capacity
LX40A
LX60A
Engine oil capacity
Replacement
1800 c.c.
1900 c.c.
Disassembly (oil
filter replaced)
1900 c.c.
2000 c.c.
Disassembly
2000 c.c.
2300 c.c.
Gear oil capacity
Replacement
330 c.c.
Disassembly
350 c.c.
Coolant capacity
Engine & radiator
1400 c.c.
1500 c.c.
Reservoir
350 c.c. as indicator shown
Total
1750 c.c.
1850 c.c.
Torque Value
Engine mounting bolt 4.0~5.0kgf-m
Engine hanger bolt 3.5~4.5kgf-m
Rear shock absorber connection bolt (under) 2.4~3.0kgf-m
Engine hanger stopper nut 1.8~2.2kgf-m
Engine bracket nut 4.0~5.0kgf-m
