Body covers disassemble sequence:
 Be careful not to damage various covers in assembly or disassembly operation.
 Never injure hooks molded on the body covers.
 Align the buckles on the guards with slot on the covers.
 Make sure that each hook is properly installed during the assembly.
 Never compact forcefully or hammer the guard and the covers during assembly.
Rear fender
Under cover
R/L. lower handle covers
R/L. floor panel
Upper handle cover
Luggage box
Double seat
Front fender
Wind screen
Front upper cover
Meter visor
Meter panel
Rear back seat
Front under spoiler
R/L. body cover
R/L. side cover
Air box
Inner box
Maintenance cover
R/L. grip
Wind screen garnish
