7. Cylinder / Piston
7-1
Mechanism Diagram························ 7-1
Precautions in Operation ················· 7-2
Troubleshooting ····························· 7-3
Cylinder / Piston Removal ················ 7-4
Piston Ring Installation ··················· 7-7
Piston Installation ··························· 7-8
Cylinder Installation ························ 7-8
Mechanism Diagram
Home page
Contents
1.0~1.4kgf-m
0.8~1.2kgf-m
7
1.2~1.6kgf-m
1.0~1.4kgf-m
