Sym MaxSym 600i ABS Service Manual

6
. Cylinder Head / Valve
6-1
Mechanism Diagram ······················· 6-1
Precautions in Operation ················· 6-2
Troubleshooting ····························· 6-3
Cylinder Head Removal ··················· 6-4
Cylinder Head Disassembly ············· 6-6
Cylinder Head Inspection ················ 6-8
Valve Stem Replacement ················ 6-10
Valve Seat Inspection and Service ··· 6-11
Cylinder Head Reassembly ············· 6-13
Cylinder Head Installation ··············· 6-14
Valve Clearance Adjustment ············ 6-16
Mechanism Diagram
Home page
Contents
6
3.6~4.0 kgf-m
2.0~2.4 kgf-m
1.0~1.4 kgf-m
1.0~1.4 kgf-m
1.0~1.4 kgf-m
1.0~1.2 kgf-m
0.7~1.1 kgf-m
