Sym MaxSym 600i ABS Service Manual

1. General Information
1-12
Frame Torque Values
Item
Q’ty
Thread Dia. (mm)
Torque Value (Kg-m)
Remarks
Mounting bolt for steering handle
post
1
10
4.0~5.0
Lock nut for steering stem
1
BC1
1.0~2.0
Steering top cone race
1
BC1
2.0~3.0
Front wheel axle nut
1
12
5.0~7.0
Rear wheel axle nut
1
16
11.0~13.0
Front cushion mounting bolt
4
10
3.5~4.5
Rear cushion upper connection bolt
1
10
3.5~4.5
Rear cushion under connection bolt
1
8
2.4~3.0
Rear fork mounting bolt
2
10
4.0~5.0
Brake hose bolt
2
10
3.0~4.0
Brake air-bleeding valve
1
6
0.8~1.0
Front brake disc mounting bolt
5
8
4.0~4.5
Rear brake disc mounting bolt
5
8
4.0~4.5
Brake clipper mounting bolt
2
8
2.9~3.5
Engine hanger link bolt
2
12
7.5~9.5
On frame side
Engine hanger link nut
1
12
7.5~9.5
On engine side
Main standard nut
1
10
4.0~5.0
Air cleaner bolts
2
6
1.0~1.4
