11. Crankshaft / Crankcase
11-7
Install the oil separator (bolt x2).
Tighten the bolts on the left crankcase ( bolt x 11).
Tighten the water pump shaft locknut.
Install the cam chain and tensioner.
To this chapter contents
Bolt x 11
