4. Fuel Injection System
4-37
l
Continued from previous page
Closed-loop
systems for
mobility
● O2 sensor
voltage is
maintained in a
long time within
a certain range
beating
● O2 sensor fault
● ECU fault
● O2 sensor
voltage beating
specifications:
100 ~ 900 mV
from the two
groups within
the interactive
beating
NG
YES
● Use diagnosis
tool to detect of
the manifold
pressure
Engine
vacuum
● Diagnosis tool
manifold
pressure for
compliance with
specifications?
● Valve clearance is
not normal
● Intake system leak
● Manifold
pressure
Specifications:
32~38 kPa
NG
Normal starting
Can not starting or starting difficulties
In traditional engine overhaul way to
maintenance
Finish
YES
YES
To this chapter contents
● Observation O2
senslor voltage
changes (Standed
motorcycle so that
engine speed
refueling between
4500 to 5500 rpm
