Sym MaxSym 600i ABS Service Manual

4. Fuel Injection System
4-39
Air Cleaner
Clean air cleaner element
Remove air cleaner cover (bolt×8).
Remove air cleaner filter (bolt×6).
Use compressed air to remove the adhesion of dirt,
if not too much dirt cleared, please new
replacement.
Cautions
● Air cleaner filter for paper products, must not
soak or cleaning by water.
Install air cleaner element
Install In the anti-demolition order.
Cautions
● Air cleaner filter and air filter cover should be
covered formation is the installation, not to
skew a seam, resulting dust, foreign body
aspiration in the engine.
Bolt × 6
Air catheter fixed bolts × 1
