1. GENERAL INFORMATION/TROUBLE DIAGNOSIS SYM
1-10
TORQUE VALUES (ENGINE)
ITEM Q'TY
THREAD DIA
(mm)
TORQUE
VALUE(Kg-m)
REMARKS
A.C. generator flange bolt 2 6 0.8~1.2
L side cover plate pan screw 7 5 0.5~0.7
RR. brake shoe anchor fixing
nut
1 8 1.5~2.0
Rear brake arm flange bolt 1 6 0.7~1.1
Engine oil filter screen cover 1 30 1.0~2.0
Crankcase bolts 2 6 0.8~1.2
Oil pump flat screw 2 6 0.8~1.2
Cylinder/cylinder head
two
-
ends bolts
4 8 0.7~1.1
Tighten to crankcase
Cylinder head left side
bolts
2 6 0.7~1.1
Camshaft sprocket bolt 2 6 1.0~1.5
Valve adjustment fixing nuts 2 5 0.7~1.1 Apply oil to thread
Camshaft chain tensioner
pivot bolts
1 6 0.8~1.2
Camshaft chain adjuster
bolts
2 6 0.8~1.2
A/I fixing flange bolt 4 6 0.8~1.2
Oil pump separator bolt 2 6 0.8~1.2
One-way clutch lock nut 1 22 9.0~10.0 Apply oil to thread
Right crankcase cover bolts 10 6 0.7~1.1
Pulse generator bolts 2 5 0.4~0.6
A.C. generator flange bolt 2 5 0.8~1.2
Flywheel nut 1 12 5.0~6.0
Cooling fan flange bolt 4 6 0.8~1.2
Shroud A/B 2 6 0.7~1.1
Engine oil draining plug bolt 1 12 3.5~4.5
Start motor bolts 2 6 0.7~1.1
Transmission bolts 7 8 2.6~3.0
Gear oil draining plug 1 8 1.0~1.5
Gear oil filling bolt 1 8 1.0~1.5
Driven pulley nut 1 12 5.5~6.0
Driving face nut 1 12 5.0~6.0
Left crankcase cover bolts 8 6 0.8~1.2
Cylinder head holder nuts 4 8 1.8~2.2
Cylinder head cover bolts 4 6 0.8~1.2
Spark plug 1 10 1.0~1.2
Carburetor heat protector
connecting nuts
2 6 0.7~1.1
Exhaust pipe bolts 2 8 3.0~3.6
Exhaust pipe connecting
nuts
2 6 1.0~1.4
