Sym Orbit II 50 4T User Manual

SYM 16. ELECTRICAL EQUIPMENT
16-1
MECHANISM DIAGRAM ................... 16-1
PRECAUTIONS IN OPERATION ...... 16-2
TROUBLE DIAGNOSIS..................... 16-4
CHARGING SYSTEM........................ 16-5
IGNITION SYSTEM ........................... 16-11
STARTING SYSTEM......................... 16-14
METER .............................................. 16-15
LIGHTS/BULBS ................................. 16-17
SWITCH............................................. 16-19
FUEL UNIT ........................................ 16-22
MECHANISM DIAGRAM
Spark plug
Fuel unit
Ignition coil
Main switch
Starter magnetic
switch
Light/starter switch
Horn/turn signal
light/high & low
beam
Front stop switch
Rear stop switch
Auto by
-star
REG.REC
C.D.I
/
B
attery
/
fuse box
Winker relay
Horn
