10. A.C. GENERATOR/STARTING CLUTCH SYM
10-2
PRECAUTIONS IN OPERATION
General information
Ÿ Refer to chapter 5: Engine removal and installation
Ÿ Refer to chapter 1: The troubleshooting and inspection of A.C. generator
Ÿ Refer to chapter 16: The service procedures and precaution items of starter motor
Specification Unit: mm
Item Standard value Service Limit
ID of starting driven gear 32.0 32.060
OD of starting clutch cover 28.0 27.940
Torque value:
Flywheel nut 5.0~6.0kgf-m
Exhaust muffler bolt 8 mm 1.5~2.0kgf-m
Oil screen cover 1.3~1.7kgf-m
Starting clutch hex lock nut 9.0~10.0kgf-m with oil on the thread
Starting clutch hex socket bolt 1.0~1.4kgf-m with adhesive
Special service tools
Flywheel puller
Universal fixture
