5. REMOVAL OF ENGINE SYM
5-2
OPERATIONAL PRECAUTIONS
General Information
Ÿ Engine must be supported by a bracket or adjustable tool in height.
Ÿ The following parts can be serviced with the engine installed on the frame.
1. Carburetor
2. Driving disk, driving belt, clutch, and transporting disk
3. Final reduction gear mechanism
Specification
Item Specification
Replacement 950 c.c.
Engine Oil Capacity
Disassemble 700 c.c.
Replacement 180 c.c.
Gear Oil Capacity
Disassemble 170 c.c.
Torque Values
Engine suspension bolt (frame side) 4.5~5.5kgf-m
Engine suspension nut (engine side) 4.5~5.5kgf-m
Bolt of rear shock absorber upper connection 3.5~4.5kgf-m
Bolt of rear shock absorber lower connection 2.4~3.0kgf-m
