11. CRANKCASE/CRANKSHAFT SYM
Remove the crankshaft from the right
crankcase.
Caution
Remove gasket and dowel pins (2).
Scrape gasket residues off the crankcase
contact surface.
Caution
Remove oil seal from the left crankcase.
l Do not damage contact surface of the
crankcase.
l Soap the gasket residues into solvent
and the residues will be removed
easily.
l The left and right bearings of crankshaft is
to press-fit onto the crankshaft.
To Next Page
