To this chapter contents
11. Steering / Front Wheel / Front Fork
Installation
11-18
Caution
y Rotate the fork pipe during installation will
make it easier to install the fork pipe.
Wolf Classic 125
Install the fork pipe from the bottom of the
front fork. Align the fork pipe cap with the top
bridge.
Hold the fork pipe by hand and tighten the
front fork upper bolt and nut.
Tighten the fork bolt on the steering stem.
Torque value：3.0~3.5kgf-m
Tighten the front fork upper bolt and nut and
confirm the specified torque value.
Torque value：3.0~3.5kgf-m
Fork pipe cap
Top bridge
Fork pipe
Bolt, nut
Boltx1
Bolt, nut
To Next Page
