13. Electrical System
13-19
Winker bulb replacement
Remove the winker lens.
Press the winker bulb slightly and rotate it
clockwise.
Remove the winker bulb.
Replace the winker bulb if it is burned out.
Specification
：
Winker bulb
12V 10W
Installation
Install in the reverse order of removal.
