6. Engine Removal
To this chapter contents
Remove the front exhaust pipe holding nuts.
(Nut X 2)
6-5
Nut×2
Remove the rear exhaust pipe holding nuts.
(Nut X 2)
Remove the exhaust pipe.
Remove the footrest (bolt×4)
Loosen the clutch cable holding nut and
adjusting nut. Pull the clutch lever and
release the clutch cable.
Nut×1
Holding nut
Clutch lever
Bolt×4
Adjusting nut
