CHECKING THE AIR CLEANER
If air cleaner is clogged by dust, engine performance and
fuel economy will be affected, so, it’s important to do periodic
maintenance.
1. Remove the left side cover by removing the one screw.
2. Remove the air cleaner cover by removing the three
screws.
3. Remove the air cleaner element. Wash the element in
clean solvent and wrap it in dry cloth to try thoroughly.
4. Soak the element in clean gear oil (SAE 30W) then
squeeze out excess oil and install it back.
Procedures for cleaning air cleaner element:
Gasoline or low flash point solvents are highly flammable
and must not be used to clean the element.
Don’t keep too much oil in the element, or the engine
performance will be affected.
1.clean. 2.squeeze dry. 3.soak in engine oil. 4.squeeze dry
CAUTION:
! Dust deposit is one of the major causes of reducing output horsepower and increasing fuel
consumption.
! Change the air cleaner element or clean it more frequently to prolong the engine’s service life if
the motorcycle is driven on dusty roads very often.
! If air cleaner is installed improperly, dust will be absorbed into cylinders, which may cause a
premature wear and reducing output power and engine life.
! Be careful not to soak the air cleaner when washing the motorcycle. Otherwise, it will cause
engine hard to start.
TOOL KIT
The tool bag is stored below the battery. The tools
in the tool bag can support general maintenance.
Check The Exhaust for unusual.
Make Sure All The Previous Abnormalities Have Been Solved.
