11.When there is an abnormal condition or a trouble
30
DIAGNOSIS WHEN ENGINE DOES NOT STAR
(1).Has the ignition switch key
been turned to “ON”
position?
(2).Is there enough fuel in the fuel
tank?
(3).Is the rear or front wheel
brakes applied when pressing
starting button?
(4). Do you rotate the throttle valve handle while
pressing starting the button?
(5). Turn the ignition switch key “ON”, and press
horn button down, if the horn does not sound,
the fuse may have been blown.
【Have your motorcycle checked by SYM authorized dealer or franchised dealer immediately if there are no
problems with the above items and engine still can not be started.】
12. C.D.I. ELECTRICL IGNITION SYSTEM
The charge and discharge principle of a condenser is adopted for the C.D.I system to supply electrical
energy created by generator’s coil, to the ignition coil in accordance with specified ignition timing so that the
spark plug may generate sparks as required.
13. SUGGESTIONS ON ENGINE FUEL
! This motorcycle is designed to use UNLEADED gasoline of Octane No. 90 or higher.
! If the motorcycle is operated in high attitude (where the atmosphere pressure is lower), it is suggested
that the air/fuel ratio should be readjusted to maximize the engine performance.
Horn button
Turn signal
light switch
1/4
1/8
