9. Crank / Crankcase / Shifting gear
Mechanism Diagram ··························· 9-1
Precautions in Operation···················· 9-3
Troubleshooting·································· 9-4
Crankcase Disassembly ····················· 9-5
Crankshaft Inspection························· 9-7
Transmission Disassembly··············· 9-8
Transmission Inspection··················· 9-9
Crankcase Inspection························ 9-10
Crankcase Assembly························· 9-11
9
Mechanism diagram
Crankcase / crankshaft
1.0~1.4
kgf-m
0.8~1.2kgf-m
3.5~4.5
kgf-m
1.0~2.0kgf-m
8.5~10.5kgf-m
9-1
To Next Page
