10. Cooling System
Precautions in operation
General information
Caution
● While the engine is running, never attempt to open the radiator filler cap, the pressurized hot
coolant may shoot out and cause serious scalding injury. No maintenance work is allowed to
perform unless the engine is completely cooled down.
● Refill the radiator with distilled water or specified additives.
● Add coolant to the reservoir.
● The cooling system can be serviced on the motorcycle.
● Never spill the coolant to the painted surface.
● Test the cooling system for any leakage after the repair.
● Please refer to Ch3 for inspection of TW sensor.
Specification
Item
Specification
Pressure to open filler cap 0.75~1.05 Kgf/cm²
Capacity of coolant: Engine + radiator
Reservoir
1200c.c.
400c.c.
Thermostat
Begins to activate at: 82~95ºC
Stroke : 0.05~3.00mm
Boiling point
Not-pressure :107.7ºC
Pressurized: 125.6ºC
Torque Value
Water pump rotor 1.0~1.4kgf-m
Special tools
Water pump bearing driver (6901) SYM-9100100
Water pump oil seal driver (Inner) SYM-9120500-H9A
Water pump mechanical seal driver SYM-1721700-H9A
Inner bearing puller SYM-6204020
Troubleshooting
Engine temperature too high Engine temperature too low
● TW sensor malfunction.
● Thermostat seized.
● Insufficient coolant.
10-2
● Water hoses clogged.
● Water pump malfunction.
● Fan motor malfunction.
● The filler cap of the radiator malfunction.
● TW sensor malfunction.
● Thermostat seized.
Coolant leakage
● water pump mechanical seal malfunction
● Thermostat O ring deterioration.
●
