12. S
teering / Front wheel / Front fork
12-4
Steering handlebar
throttle
cable
locknut
Removal
Loosen the throttle cable locknut. Remove the
right handle switch screws. (screw×2)
。
screw×2
Remove the throttle cable. Remove the
throttle grip and right handle switch.
Remove the front brake master cylinder
. (bolt
x2)
Throttle cable
bolt×2
181
183
