2. Route the cables from beneath the hole and attach to the
scanner as shown in Figure 2-12.
3. Lower the scanner into the counter hole.
Option B- Flush with the counter top
1. On the counter top, measure two concentric squares: an
inside square of 6.81 in. (173 mm), and an outside square
of 7.91 in. (201 mm) (Figure 2-14)
2. Cut out the 6.81 in. (173 mm) inner square.
3. With a router set to the appropriate depth, route out the
outside square. The corner radius should not exceed
0.20 in. (5 mm).
- LS-5800-I210DN: depth = 0.05in. (1.2mm)
- LS-5800-I210SN: depth = 0.05in. (1.2mm)
